UNCT3300-A
UNICOMP
Function Application:
Equipment Features：
All-round high-precision detection: Advanced dual-source, dual-detection system to meet different testing needs. The detection ability is leading in the industry.
Powerful feature: With DR and CT dual imaging detection function; with a super large detection range, widely applicable, cost-effective.
High security: High level of protection, the radiation level is far below the national standard; Set up with multiple safety measures.
Easy to operate: The humanised control system is simple and easy to operate, and can be mastered after a short training.
Technical Parameters and Specifications:
| System Summary | |
| Equipment body dimensions | 3300*1230*2600mm |
| Machine Weight | 8T |
| Power Supply | 380AC/50Hz |
| Power Consumption | 15 kW |
| Console | Freestanding Operating Console |
| X-Ray Tube（Microfocus） | |
| X-ray Tube Type | Split tube |
| Voltage | 225kv |
| Focus size | ＜4μm |
| X-ray Power （Maximum） | 320W |
| X-Ray Tube | |
| X-ray tube type | Split tube |
| Voltage | 450kV |
| Focus size | 0.4/1.0mm（EN12543） |
| X-ray Power （Maximum） | 1500W |
| Imaging System（Flat Panel Detector） | |
| Detector | Amorphous silicon |
| Pixel Size | 139μm |
| Effective Detection Area | 427*427mm |
| Pixel Matrix | 3072*3072 |
| Imaging System（Line Array Detector） | |
| Detector | CdWO4 |
| Effective length | 614mm |
| Pixel size | 0.2mm |
| Maximum scanning speed | 44cm/s |
| Motion Control System | |
| Max.detection range | φ800*1000[mm] |
| Max.loading weight | 100 kg |
| Software | |
| Coordinate measurement module, design parts/objects comparison module, wall thickness analysis module, pore inclusion analysis module, fiber composite material analysis module, extended version pore/inclusion analysis module, manufacturing geometry correction module, volume grid calculation module, structural mechanics simulation module, transfer field simulation module and other functions are available. | |
| * Specifications are subject to change without notice, All trademarks are the property of the system maker. | |
Inspection Images:
Dimensions and Appearance:
