AX9100
UNICOMP
Widely applied for BGA , CSP , Flip Chip, LED , Fuse,Diode, PCB, Semiconductor, Battery Industry, Small Metal Casting, Electronic Connector Module, Cables, Photovoltaic Industry, etc.
Application Fields
SMT/PCBA
Semiconductor
Lithium Batteries
LED
Photovoltaic
Functions and Feature
1. Strong penetrating ray source combined with HD FPD to meet universal inspection requirements
2. High Definition Navigation Images, Fast And Accurate Product Positioning
3. Six-axis Linkage to Achieve All-round Control And Detection
4. High Speed CNC Function For Batch Automatic Inspection
5. 2 Sides Tilting
6.Adjustable Console
Inspection Image
System Summary | |
Footprint | 1470(W)×1410(D)×1805(H)mm |
Machine Weight | 2100 kg |
Power Supply | AC 110~220V, 50/60Hz |
Plywood Packing Size | 1650(W)×1800(D)×2000(H)cm |
Packing Weight | 2300 kg |
Power Consumption | 3.5kW |
X-Ray Tube | |
Tube Type | Sealed |
Max. Power | 65W |
Voltage | 0~130kV (Adjustable) |
Focus Spot Size | ≤7μm |
Imaging System | |
Detector | Flat Panel Detector (FPD) |
Pixel Size | 84μm |
Effective Detection Area | 129*129mm |
Frame Rates | 20fps |
Pixel Matrix | 1536*1536(pixel) |
System Magnification | 1600X |
Software | |
Auto-measuring | BGA Soldering Voids Auto-measuring and Support Data/Graphic Output |
Multiple Measuring Tools | Support Measuring Distance, Angle, Diameter, Polygon, PTH filling rate, etc |
CNC Mode | CNC Programmable Inspection, Easy Operation and User Friendly |
Real-time Display | Real-time Displaying the Working Data of Voltage, Current, Angle, Date, etc |
Navigation | Convenient Target Point Positioning System |
Motion Control System | |
Movement Control | Joystick, Keypad & Mouse |
Max. Loading Area/Weight | 610*610mm/ 10kg |
Max. Inspection Area | 500*450mm |
Oblique Views | Max. ±60° Filting (FPD) |
Manipulator | 6-axis with X1 / X2 / Y / Z1 / Z2 / T (55°) /R (360°) |
Industrial PC | |
Monitor | 21.5’’ FHD LCD Display |
System OS | Windows 10 64bit |
Hard disk | 1TB |
RAM | 16GB |
CPU model | Intel i7 Processor |
Other Features | |
Energy Saving | X-Ray Auto-off when it's out of work over than 5 minutes |
Safety Operation | Electromagnetic Interlock and warning Light |
Authority Management | Password Magnagement |
X-Ray Safety | <1μSv/h (Meets All International Standards) |
* Specifications are subject to change without notice, All trademarks are the property of the system maker.
